With new regulations in effect like HIPAA and GLB-Act, and standards such as ISO 27000 series, keeping company, employee and customer information private is mandatory. Our degaussers will help you meet these new physical safeguard regulations by completely demagnetizing all data from hard drives and tapes.
Although the degausser models listed below have been designed to erase hard drives, their strong degaussing fields will also erase today's high-coercivity tape such as DLT, SDLT, 3480's, AIT and more.
Degaussing gives you in-house control of all sensitive and private information. Computers have been designed to be resilient. They allow information to be recovered if accidentally deleted or even if the hard drive has been reformatted. Even after deleting or reformatting the hard drive, magnetic patterns of existing data still exists on the disk platters. Degaussing demagnetizes the entire hard drive including the disk platters - leaving no magnetic patterns on the hard drive.
Once degaussed, the hard drive will be unusable and will not be recognized by the computer. In fact, the erasure is so deep that the factory written servo tracks on the disk platters are also demagnetized leaving no reference points for the read heads to key in on.
When disposing of computer hard drives, it is simply not enough to delete, reformat or overwrite the information. The only solution that guarantees 100% data erasure form hard drives is to use a degausser.
The process of degaussing is achieved by passing the hard drive, through a powerful magnetic field, which rearranges the metallic particles, completely removing any resemblance of the original data. Even if the hard drive is not working, the degaussing process can be used to ensure that data contained is removed completely and cannot be recovered.
Note: Non-working hard drives contain all of the original data and can be easily recovered. Degaussing provides the quickest (under 30 seconds) and most complete erasure of all hard drives.
The HD-3WXL is the newest and most innovative product in Garner’s line of hard drive and tape degaussers. The user friendly input system provides effortless loading of various sized hard drives and tape media without the need for adapters. Once degaussed, the media is automatically released down the exit chute. The HD-3WXL erases all hard drive and tape formats that fit into the 6.75 x 4.5 x 1.8 inch degaussing chamber including large network sized hard drives. Media formats include hard drives, LTO, SuperDLT, DLT, 9940, 3592, AIT and more.
The HD-3WXL erases full height (1.66" in height), standard height and laptop hard drives and high coercivity tape media including all formats of LTO (1, 2, 3 and 4), SuperDLT I & II, DLT, 9940, 3592, AIT, 8mm and more, all without any adapters. With a continuous duty rating (no cooling necessary) and 10 second cycle time, even large quantities of media can be erased in a very short period of time.
HD-3WXL Operations:
The HD-3WXL is exceptionally user-friendly. Simply slide your media into the slot on the left side of the HD-3WXL and push the "Erase" button. Within two seconds your media will be completely erased and will automatically slide out the right side of the HD-3WXL. It just doesn’t get any easier than that! If space is at a premium, the HD-3WXL's compact design takes up just over 1 square foot.
Degauss vs. Overwrite:
The HD-3WXL produces an erasing field several times stronger than the erasing fields produced by the read/write heads in hard drives and tape drives. This makes for a deeper and more efficient erasure than software based wiping programs. Since the HD-3WXL does not rely on software, the HD-3WXL will also completely and permanently erase failed and damaged hard drives regardless of the operating system or interface.
Key Features
~ Single Pass Automatic Operation
~ Over 250 drives erased per hour
~ Complete erasure of hard drives and tapes
~ Processor Controlled operation for Failsafe erasure
~ Effective on Longitudinal & Perpendicular Hard Drives
~ FREE lifetime technical support
~ Transport Case Available
Fully Automatic Degausser, securely erases hard drives and tapes.
The DATAGONE is a fully automatic degausser for Hard Drives and Backup tapes. It uses pulse discharge technology and is fully processor controlled which enables the DATAGONE to offer a complete and secure erase on magnetic media. Media that can be degaussed includes Hard Drives that use both perpendicular and vertical recording techniques and most common backup tapes including DLT, LTO, 8mm, DDS and more.
Perfomance
The DATAGONE generates a powerful magnetic field and in less than a second completely erases the complete data from Hard Drives and Backup tapes. Its simple one pass fully automatic operation makes it ideal in businesses where security is of the utmost importance.
Operation
The DATAGONE is a fully automatic table top mounted unit. With the Datagone powered up the operator simply slides the hard drive into the aperture on the left hand side of the unit. The unit senses the presence of the media and the degauss cycle starts automatically. No operator action is required. When the degauss cycle is complete, the hard drive is released and exits from the degausser on the right hand side. Throughout the entire degauss cycle the onboard processor monitors the procedure and progress messages are displayed on the LCD panel.
If the degauss cycle is interrupted for any reason such as power loss or any fault condition, the media is retained in the DATAGONE and the operator is immediately alerted to the interruption in the erasure cycle on the LCD panel.
To eject media when the cycle has failed for any reason the operator has to press the reset button. This releases the Hard Drive or Tape and resets the degauss cycle. The operator should then attempt a repeat erasure. The entire erasure process takes approximately 8 seconds.
Specifications
Media Handling:
3.5", 2.5" & 1.8" hard drives. Longitude &perpendicular (Up to 3TB); DLT, S-DLT, LTO1, 2, 3, 4 & LTO5; 3480/3490/3490e, 3590, 9840 & T9940 tape; Ultrium & Redwood SD-3 tape & cartridges; Mammoth 1 & 2, 8mm, AIT1 & 2,M2 tape; DDS 1, 2, 3, 4 & 5, DD-2 & DFT-1 & 2
Power Supply: 230V AC 50Hz / 115V AC 60Hz
Current Rating: 50Hz 5 Amps, 60Hz 9 Amps
Gauss Force: 10,000 max gauss
Cycle Time: 8 seconds typical
Display: Liquid Crystal Display (LCD)
Dimensions (WxHxD): 14.3” x 14.3” x 19.2” (362mm x 362mm x 487mm)
Unit Weight: 63.8lbs (29kgs)
Packed Weight: 74.8lbs (34kgs)
Throughput: 200 hard drives in one continuous session or up to 275 hard drives per hour
Controls: On/Off Power switch, Reset button
Transport Case: Available as an optional extra
Warranty: 12 months back to base, all parts and labor included. Extended warranties also available.
Specifications are subject to change without notice
The PD-8700 is designed to provide a safe, convenient and effective method of destroying confidential information contained on hard drives. The PD-8700 degausses and then physically destroys the hard drive ensuring that the information previously contained on the hard drive is permanently erased and destroyed.
The PD-8700 meets compliance standards for government mandates requiring complete elimination of private and confidential information stored on hard drives prior to disposal.
The PD-8700 is actually two machines in one. First, it is a powerful degausser rated at 10,000 gauss. Secondly, it is a Physical Hard Drive Destroyer that pierces holes into the data platters rendering the hard drive physically unusable. For flexibility, the PD-8700 allows the user to chose between “Auto” mode - performs both degauss and destroy modes, “Erase” mode or Destroy mode.
The Erase mode of the PD-8700 features a degaussing force of 10,000 gauss and a large tray size to accommodate today's high coercivity drives as well as older, larger sized hard drives. Stored energy is quickly released to produce short, focused erasing fields that penetrate through the hard drive housing, changing the magnetic properties contained on the data disk platters.
Because the PD-8700's erasing field is many times stronger than the writing and erasing heads inside the hard drive, the PD-8700 will provide superior erasure over re-write programs that rely on the hard drive's internal write heads.
The Destruction mode of the PD-8700 is designed to physically disable the hard drive, preventing data from being recovered. The physical destruction visibly identifies hard drives that have been properly sanitized.
The PD-8700 accommodates all formats and sizes of hard drives up to 4.5" wide and 1.66" high. The PD-8700 does not rely on software, therefore it will erase all operating systems. In addition, degaussing is the only way of erasing hard drives that are not functioning.
New security and privacy mandates now require complete erasure of media containing sensitive and confidential information prior to the re-use or disposal of the media.
Today's magnetic recording formats allow for more data storage, better video resolution, less video noise and higher frequency recording. The problem is these super-high coercivity media formats - 2400 oersteds for tape and 3000 oersteds for hard drives - are increasing and are very difficult to erase. Conventional tape erasers just can't do it. The solution is the CDS-4400ED Eliminator!
The CDS-4400ED Eliminator erases metal particle tape to -80dB (like new) in 12 seconds or less. IT departments will be able to erase the data including all format and control track information on DLT's allowing them to be re-used in other DLT drives. Further, IT departments are increasing there data security by degaussing hard drives before disposing of or transferring hard drives out of a secured environment.
Please note: Degaussing of hard drives erases all data, formatting and the factory installed magnetic servo tracks located on the hard disc platters. Therefore, the hard drive will be unusable after degaussing.
Broadcasters, video professionals and data centers save money through erasing and reusing their metal tape. And they don't sacrifice program integrity because the CDS-4400ED Eliminator provides like new erasure quality.
The world's leading tape manufacturers recommend the CDS-4400ED Eliminator. This is because it features patented technology that eliminates excessive heating of aluminum hard drive casings, metal cassette parts and reels that can damage tape. And this is done without compromising erasure quality.
The CDS-4400ED Eliminator will erase all formats including: Hard Drives, One-inch Tape Reels, VHS, U-Matic, S-VHS, MII, D1, D2, D3, D5, 4MM, 8MM, DLT, LTO Ultrium I-IV, HI8, DAT, DIGITAL BETACAM SP, DVCAM, DVCPRO, DIGITAL-S, HDTV and MIRROR IMAGE.
The popular CDS-4400ED Eliminator digital tape degausser is incorporates electro-magnetic field (EMF) shielding. The specially designed shielding reduces radiated EMFs by more than fifty-percent. The simple to operate CDS-4400ED Eliminator is the first conveyor belt style bulk degausser to offer EMF shielding. Now bulk degausser users can greatly reduce their exposure to EMFs without compromising tape erasing quality or productivity. This is a welcomed development for many broadcasters and production facilities that have standardized on the CDS-4400ED Eliminator.
The HDTD-8750 is a large capacity Hard Drive and Tape Degausser capable of erasing Laptop Computers and hot swappable hard drives with mounting hardware attached. In addition, the HDTD-8750's large capacity allows the erasure of up to 6 hard drives, 9 DLT's (SDLT, SDLT-600, LTO's), or several large tape reels at one time.
The HDTD-8750 is designed to permanently eliminate data contained on Hard Drives, Laptop Computers, Tape Cartridges and Tape Reels.
The HDTD-8750 erases all media formats and sizes. The large opening of the HDTD-8750 allows it to erase up to six (6) hard drives or nine (9) DLT, SDLT or SDLT II media at one time. The HDTD-8750 will erase any format of magnetic media up to 2½" high, 14" in length and 12½" in width, including laptop computers.
Simple operation allows non-technical operators to erase all formats of media without the confusion of using complicated adapters.
Operation is easy. Place media in the pull out tray, slide the tray back in, push the erase button and the HDTD-8750 will do the rest. When the operation is complete (approximately 2 minutes), you may safely reuse the media or dispose of it.
The HDTD-8750 conveniently operates on standard wall voltages and can be easily moved as it comes standard with casters.
SDD Master NSA Government Approved, High Security Hard Drive Degausser. A high energy, chamber-style pulse degausser designed to offer complete and secure erasure of magnetic media, to the highest security level, including perpendicular & longitude recording hard drives. Also capable of erasing data storage media including LTO, 8mm, DDS and more. Typical throughput is 40 hard drives per hour. Manual or remote control operation.
SV91 CESG & NATO Approved Hard Drive and Tape Degausser. A high energy, degausser especially designed to eliminate all data from computer, laptop and server hard drives. Will also erase data from high coercivity tape, including LTO, DLT, Super DLT, AIT, and more. Manual or infra red remote control operation.
V91 HD/DLT Hard Drive & DLT Tape Degausser. The V91HD/DLT is a high energy, bulk eraser especially designed to tackle the erasing of computer hard drives and DLT tapes. With a powerful 7000 gauss field, the V91 HD/DLT is our best selling table-top degausser.
V6000 Automated, high-volume hard drive degausser. A state-of-the-art one pass conveyor degausser designed for the volume erasure of hard drives. The specially designed high intensity coils ensure complete erasure of hard drives in large quantities, perfect for IT logistic and security providers.
V660 Hard drive degausser with infrared remote control. A high energy, degausser especially designed to eliminate all data from computer, laptop and server hard drives. The V660 will also erase data from high coercivity tape, including LTO, DLT, Super DLT, AIT and more. Hard drives are completely erased in just 20 seconds, making it the fastest hard drive degausser available.
Hard Drive Destroyers |
The VS7000 Manual Hard Drive Destroyer is designed for the physical destruction of all standard and laptop hard drives. Specifically designed for emergency situations where electric power may not be available and quick destruction is a must, the VS7000's low cost and versatility makes it perfect for both the government and commercial market where a tight budget is an important consideration.
The VS7000 takes less than 15 seconds to destroy each hard drive. All one needs to do is to insert the proper drive height adaptor into the slot and crank the handle 8 rotations. The internal workings of the unit press down on the drive, bending it approximately 90 degrees, rendering the hard drive useless by bending the platter, damaging the heads, motor and circuit board.
In commercial applications, the VS7000 is an inexpensive alternative to expensive power destroyers, shredders. The VS7000 offers visible proof that the hard drive is, destroyed. Because the VS7000 requires a minimal amount of manual power, it is extremely operator friendly.
The PD-4 physically destroys hard drives by bending, breaking and mangling the hard drive and its internal components including the data platters. The data platters are bent and separated from the hub, the hard drive housing is cracked, the PC board is broken and the read/write heads are mangled.
The PD-4 meets NIST, HIPAA, PCI-DSS and GLBA compliance and guidelines requiring destruction of data contained on hard drives.
The PD-4 is designed to physically destroy hard drives in order to prevent persons from being able to "spin" the hard drive up to retrieve data. The PD-4 will automatically bend, break and mangle the hard drive including the data platters - where the data is stored. Once destroyed, the data will no longer be retrievable.
The PD-4 is best utilized as the last step in your data security procedures. All other methods of data erasure leave the outside appearance of hard drives unchanged. It is impossible for the operator to distinguish a working hard drive from a non-working drive. The PD-4 will physically destroy as well as identify the hard drive as being ready for disposal. No hard drive should be disposed of without first being physically destroyed.
The PD-4 works as a stand-alone unit or in conjunction with our HD-3WXL hard drive degausser. These degaussers will assure the complete erasure and demagnetization of the information prior to destruction by the PD-4. The PD-4 is the ultimate in data security.
The PD-4 will automatically destroy all formats and sizes of hard drives including Network SCSI and IDE Drives up to 2" in height. The PD-4 doesn't rely on software, therefore it will destroy all working and non-working hard drives in a matter of seconds. A simple push of a button will ensure complete destruction and ensure your data will be securely destroyed and un-retrievable.
The PD-4 is best utilized as the last step in your data security procedures. All other methods of data erasure leave the outside appearance of hard drives unchanged. It is impossible for the operator to distinguish a working hard drive from a non-working drive. The PD-4 will physically destroy as well as identify the hard drive as being ready for disposal. No hard drive should be disposed of without first being physically destroyed.
The PD-4 has been updated with an auto height detection system. This allows the operator to save precious time when destroying today's low profile or 1" hard drives, laptop hard drives or multiple hard drives in a single sequence. Auto sensors also will allow the operator to destroy the taller half-height and network drives up to 2" in height with no additional user input. It only takes 20 seconds for the first drive to be destroyed, therefore meeting the NSA's Emergency Destruction guidelines.
To enhance the PD-4's compact size, we offer an optional carrying case on wheels. This allows the PD-4 to be easily transported to the secure location of the hard drive rather than jeopardize the data during transportation.
Hard Drive Degaussers & Destroyers |
Ensure the safety of your information by controlling your media while it is going through the end of life-cycle process. Made specifically to incorporate the HD-3W Series Degaussers and the PD-4 Physical Destroyer in to a Degauss-Destroy-Recycle System. The DDR-1 System is designed to utilize a secure area to store media before degaussing and manage degaussed and destroyed media after processing using color coded bins and a special recycling container.
Theft or loss of hard drives is a serious security threat. Controlling your magnetic media during the end of life-cycle process in a manner that conforms to government mandates is key to any compliance policy.
The Secure Workstation supporting an HD-3 series degausser allows users to deposit media ready to be degaussed in the secure drop slot on the top of the workstation. Media can be removed for degaussing by opening the secure cabinet underneath the table to begin the decommissioning process.
The PD-4 physically destroys hard drives by bending, breaking and mangling the hard drive and its internal components including the data platters. The data platters are bent and separated from the hub, the hard drive housing is cracked, the PC board is broken and the read/write heads are mangled.
The PD-4 meets NIST, HIPAA, PCI-DSS and GLBA compliance and guidelines requiring destruction of data contained on hard drives.
The PD-4 is designed to physically destroy hard drives in order to prevent persons from being able to "spin" the hard drive up to retrieve data. The PD-4 will automatically bend, break and mangle the hard drive including the data platters - where the data is stored. Once destroyed, the data will no longer be retrievable.
The PD-4 is best utilized as the last step in your data security procedures. All other methods of data erasure leave the outside appearance of hard drives unchanged. It is impossible for the operator to distinguish a working hard drive from a non-working drive. The PD-4 will physically destroy as well as identify the hard drive as being ready for disposal. No hard drive should be disposed of without first being physically destroyed.
The PD-4 works as a stand-alone unit or in conjunction with our HD-3WXL hard drive degausser. These degaussers will assure the complete erasure and demagnetization of the information prior to destruction by the PD-4. The PD-4 is the ultimate in data security.
The PD-4 will automatically destroy all formats and sizes of hard drives including Network SCSI and IDE Drives up to 2" in height. The PD-4 doesn't rely on software, therefore it will destroy all working and non-working hard drives in a matter of seconds. A simple push of a button will ensure complete destruction and ensure your data will be securely destroyed and un-retrievable.
The PD-4 is best utilized as the last step in your data security procedures. All other methods of data erasure leave the outside appearance of hard drives unchanged. It is impossible for the operator to distinguish a working hard drive from a non-working drive. The PD-4 will physically destroy as well as identify the hard drive as being ready for disposal. No hard drive should be disposed of without first being physically destroyed.
The PD-4 has been updated with an auto height detection system. This allows the operator to save precious time when destroying today's low profile or 1" hard drives, laptop hard drives or multiple hard drives in a single sequence. Auto sensors also will allow the operator to destroy the taller half-height and network drives up to 2" in height with no additional user input. It only takes 20 seconds for the first drive to be destroyed, therefore meeting the NSA's Emergency Destruction guidelines.
To enhance the PD-4's compact size, we offer an optional carrying case on wheels. This allows the PD-4 to be easily transported to the secure location of the hard drive rather than jeopardize the data during transportation.
NSA Approved Degaussers & Destroyers |
The Garner Model CF-750 II-A degausser meets the National Security Agency/Central Security Service Specifications L14-4-A and Department of Defense Manual 5200.28M for erasure of Type II-A Magnetic Media.
It features new technology which provides the fastest, most superior erasure of magnetic media today. In just 45 seconds the CF-750 II-A will erase 900 oersted media to -90dB. And its continuous duty operation allows bulk degaussing of large quantities of media.
The CF-750 II-A will erase a wide variety of today's most popular media including: S-VHS, 8 mm and 3480 cartridges. And it conveniently operates from a standard 120 VAC wall outlet. Plus, its compact design can be mounted on a standard 19" rack or it is available as a table top unit with the optional steel cabinet.
As high coercivity magnetic media becomes the industry standard, the lower energy degaussers currently in use are now insufficient for high coercivity media. Garner, the leader in degaussing equipment for over 20 years, answers with its NSA type 1 approved CDS-2700.
The CDS-2700 is designed to be used either as part of a production line, or as a stand alone unit to erase high volumes of video cassettes, diskettes, data storage cartridges and other magnetic material.
The PD-4 physically destroys hard drives by bending, breaking and mangling the hard drive and its internal components including the data platters. The data platters are bent and separated from the hub, the hard drive housing is cracked, the PC board is broken and the read/write heads are mangled.
The PD-4 meets NIST, HIPAA, PCI-DSS and GLBA compliance and guidelines requiring destruction of data contained on hard drives.
The PD-4 is designed to physically destroy hard drives in order to prevent persons from being able to "spin" the hard drive up to retrieve data. The PD-4 will automatically bend, break and mangle the hard drive including the data platters - where the data is stored. Once destroyed, the data will no longer be retrievable.
The PD-4 is best utilized as the last step in your data security procedures. All other methods of data erasure leave the outside appearance of hard drives unchanged. It is impossible for the operator to distinguish a working hard drive from a non-working drive. The PD-4 will physically destroy as well as identify the hard drive as being ready for disposal. No hard drive should be disposed of without first being physically destroyed.
The PD-4 works as a stand-alone unit or in conjunction with our HD-3WXL hard drive degausser. These degaussers will assure the complete erasure and demagnetization of the information prior to destruction by the PD-4. The PD-4 is the ultimate in data security.
The PD-4 will automatically destroy all formats and sizes of hard drives including Network SCSI and IDE Drives up to 2" in height. The PD-4 doesn't rely on software, therefore it will destroy all working and non-working hard drives in a matter of seconds. A simple push of a button will ensure complete destruction and ensure your data will be securely destroyed and un-retrievable.
The PD-4 is best utilized as the last step in your data security procedures. All other methods of data erasure leave the outside appearance of hard drives unchanged. It is impossible for the operator to distinguish a working hard drive from a non-working drive. The PD-4 will physically destroy as well as identify the hard drive as being ready for disposal. No hard drive should be disposed of without first being physically destroyed.
The PD-4 has been updated with an auto height detection system. This allows the operator to save precious time when destroying today's low profile or 1" hard drives, laptop hard drives or multiple hard drives in a single sequence. Auto sensors also will allow the operator to destroy the taller half-height and network drives up to 2" in height with no additional user input. It only takes 20 seconds for the first drive to be destroyed, therefore meeting the NSA's Emergency Destruction guidelines.
To enhance the PD-4's compact size, we offer an optional carrying case on wheels. This allows the PD-4 to be easily transported to the secure location of the hard drive rather than jeopardize the data during transportation.
NSA approved degausser for Type I, II & to 2600 Oe. Permanently erases 2.5" & 3.5" hard drives up to 1" in height, and tape formats including SDLT, DLT, LTO/LTO2, DAT, TRAVAN, AIT, QIC, 8mm and more. The rare earth magnet design produces a 13,000 oersted field and can be used with or without electrical power.
The REM-1400NSA is a powerful rare earth permanent magnet degausser. The patented magnetic design ensures complete erasure of data from tape and hard disk drives, including perpendicular media. The height adjustable stand with wheels allow the REM-1400NSA to be easily positioned and the wheels allow the REM-1400NSA to be easily relocated within your complex.
REM-1400NSA Operations: The REM-1400NSA erases media by passing the media through a large magnetic field. When powered by electricity, the REM-1400NSA will automatically transport the media through the magnetic field, rotate the media 90 degrees, and then pass the media back through the field. When operated without electricity, the transport mechanisms are manually powered by a hand crank located on the back of the REM-1400NSA.
NSA/DOD Approved: The REM-1400NSA meets the Department of Defense requirements for destroying magnetically recorded data on hard disks drives up to 5300 Oe and tape media up to 2600 Oe.
Government Mandates: The REM-1400NSA will assist you in meeting compliance standards for government mandates requiring complete elimination of sensitive information stored on magnetic media prior to re-use or disposal.
